Chamberlain Liftmaster LM70EVF Garage Door Opener Kit
£320.00
Garage door opener specifications:
- Max garage door width 5000 mm
- Max garage door height 2300 mm
- Max garage door weight 110 Kg
Included:
- 3 piece belt rail 2.3m
- Two handsets
- MyQ gateway
- Safety photocells
- Quick-release mechanism
Available
- Description
- Features
- Additional Technical Information
- Downloads
Description
Chamberlain Liftmaster LM70EVFFC garage door opener with 3 Piece Belt Rail
This all-in-one kit includes an array of accessories as standard at no additional cost. This kit comes complete with the 828EV MyQ gateway, TX4EVF 4-channel remote controls, 771E safety photocells, and a quick-release mechanism for secured access in the event of a power failure.
The compact garage door opener for a wide range of garage doors.
Super-quiet garage door opener including a modern, powerful LED lighting system. For garage doors with door weights up to 110 Kg. Compatible with MyQ smart-home technology.
Smart
Space-saving design opens up the ceiling.
Belt drive system for powerful performance.
Soft-start and soft-stop for smooth operation.
MyQ mobile app lets users receive alerts and control the opener from anywhere (Internet Gateway 828EV included).
Quiet & Reliable
Quiet DC motor eliminates noise and vibrations through the ceiling and provides smooth operation.
Heavy-lifting power operates doors up to 110 Kg.
Maintenance-free belt drive ensures quiet & durable operation.
Warranty motor: 5 years, control board: 5 years, accessories: 2 years.
Secure & Safe
Automatic garage door openers impede unauthorised access to the garage.
Timer-to-close automatically closes the door after a preset amount of time (when safety sensors connected, 771E included).
Evolution radio (security+ 2.0®) sends a new code with every remote click.
Automatic force setting & obstacle detection.
Stay connected with MyQ With MyQ, you can monitor and control your garage door, using your smartphone, tablet or computer from wherever you happen to be. |
Smart radio technology Evolution operators are equipped with the best reliable radio that is a bi-directional radio. They don't only receive signal, they also sends signals back. |
||
Strength in silence The quiet operation of our garage door openers is unparalleled. |
Up to 5 years motor warranty The long-time warranty demonstrates that LiftMaster provides premium quality products. |
||
Economic and environmentally friendly The extremely low standby energy consumption is good for the environment and your pocket. |
Long-lasting LEDs Immediate brightness, low CO2 emissions and avoidance of heavy metals and mercury in manufacturing. |
||
Quickly installed Simple installation with standard tools. |
Voltage IN | 230-240 V, 50/60 Hz |
---|---|
Motor voltage | 24V DC |
Max pull force | 700 N |
Speed | 160 mm per second |
Soft-Start and Soft-Stop | Yes |
Operating temperature | -30°C bis +55°C |
Safety class | TÜV-tested to meet EN12453. For doors up to 130 Kg |
Weight | 12 Kg |
Stand-by power | 0,8 W |
Drive type | Belt |
Max door width | 5 m |
Door height | Adjustable up to 2,5 m or up to 4 m with appropriate extension |
Max door weight | 110 Kg |
Headroom required | Min 35 mm |
Lighting | LED turns on with activation, turns off 2.5 minutes after operation |
Radio | 433 MHz + 868 MHz |
Memory registers | 180 |
MyQ smartphone compatible | Yes (optional Internet Gateway 828EV required) |
Obstacle detection | Automatic |
Force setting | Automatic |
Over voltage protection | Transformer overload protection |
Limit Switch | Electronic |
Motor warranty | 5 years |
